The ZONESUN ZS‑CB190 custom conveyor belt functions as an efficient bottle unscrambler, sorting bottles or containers with high capacity to reduce labor and increase productivity. Designed for seamless integration into automated production lines, it features adjustable working speeds up to 20 m/min, sturdy construction, and a single 190.5 mm‑wide conveyor. Powered by a reliable 1.5 kW motor, this conveyor is ideal for streamlining workflows in beverage, cosmetic, pharmaceutical, and other container‑based industries.
ZS‑CB190 — Specifications
Parameter Details
Machine Model ZS‑CB190
Voltage 220 V / 110 V, 50‑60 Hz
Power 1.5 kW
Conveyor Size 1760 × 1425 mm + 960 × 190.5 mm
Conveyor Width 190.5 mm (Single)
Working Speed 0 – 20 m/min
Package Size Approx. 2050 × 1720 × 720 mm
Package Weight Approx. 276 kg
Electrical Control Box: Houses the electrical components used to control conveyor operation.
Bottle Guiding Rails: Guide containers along the conveyor during bottle sorting.
Drive Motor: Drives the conveyor system for continuous bottle transport.
Adjustable Guide Rails: The guide rails help keep containers aligned and can be adjusted to suit different container sizes.
