The ZONESUN ZS-DTMP6M is a high-speed magnetic pump filling machine equipped with six diving nozzles for precise, splash-free filling of low-viscosity liquids. Designed for automated production lines, it handles essential oils, soy sauce, juice, vinegar, and similar products with exceptional accuracy (≤±1%). Operating at up to 50 bottles per minute, it integrates seamlessly with capping and labeling machines. With programmable delay and count settings, adjustable filling volumes from 3–1000ml, and a durable bracket-mounted design, it's ideal for cosmetics, beverages, pharmaceuticals, and daily chemical industries.
Machine Parameters – ZS-DTMP6M
Item Specification
Machine Model ZS-DTMP6M
Power Supply 110V / 220V, 50–60Hz, 300W
Max Flow Velocity 7500ml/min (based on 250ml water)
Working Speed 40–50 bottles/min (based on 250ml water)
Air Pressure 0.3–0.4MPa
Filling Accuracy ≤±1% (for water)
Filling Nozzle Diameter 6mm / 8mm
Delay Range 0.01–999.9s
Count Range 1–99999 times
Filling Volume 3–1000ml
Air Compressor Connector Size OD8mm
Package Size Approx. 860 × 720 × 1330mm
Package Weight Approx. 118kg
Independent Magnetic Pumps and Diving Nozzles
Each 316 stainless steel magnetic pump controls one nozzle independently. Diving nozzles move closer to bottles to reduce splashing and are suitable for foamy liquids.
Bottle Detection, Stable Conveying and Elevated Bracket
Electric eyes detect bottles for accurate filling, while the chain conveyor transports them smoothly. The elevated bracket allows integration with vertical capping and labeling machines.
