DESCRIPTION
Improve your packaging efficiency with our high-quality vertical premade pouch packaging machine. Equipped with 3 weighers, it can accurately fill granules and feed them in turns or mix three different granules, improving efficiency. The hopper at the top of the machine allows for easy material loading. The machine uses heat sealing technology to ensure your products are protected from external factors. Ideal for food, chemical, and cosmetic products.
Whatever your packaging needs are, you can rely on ZONESUN.
Parameter
- Machine Model: ZS-AFS04
- Power Supply: 220V 50Hz 720W
- Packaging Speed: About 20-25 bags/min (depending on filling volume)
- Filling Range: 1–100g
- Suitable Bag Size：5 × 7 cm (min) – 20 × 30 cm (max)
- Filling Accuracy: ±0.2g
- Hopper Capacity: 30kg
- Air Pressure: 0.6–0.8MPa
- Machine Weight: About 132kg
-
Machine Size: About 950*550*1550mm
PLC Control and Three-Weigher Dosing
The PLC control panel allows working parameters to be adjusted. Three electronic weighers measure granules accurately and can feed materials in sequence or combine three different materials.
Premade Pouch Feeding and Heat Sealing
Suction cups feed premade pouches into the machine. The heat-sealing system closes each pouch securely, with adjustable sealing temperature and optional date coding using letter molds.
