Why Automation Matters in Marker and Pen Manufacturing

InkPenAutomation

In the world of stationery and art supplies, especially for high-precision products like markers, watercolor pens, and ink pens, accuracy, speed, and cleanliness are key to scaling production. Manual filling and sealing not only limit output but also increase the risk of inconsistent ink volume and sealing defects.

The ZONESUN ZS-AFCU1M Monoblock Packaging Machine is engineered specifically for compact pen-style packaging solutions, streamlining the entire process from filling to capping — all while maintaining high precision and minimal footprint.

MarkerPenMachine

Key Features of ZS-AFCU1M Monoblock Machine

  • All-in-One Operation
    Integrates automatic tube loading, ink filling, cap placement, pressing, and output in a single compact system.

  • Precision Filling System
    Features a customizable peristaltic or piston pump for delivering consistent ink volumes — essential for water-based or dye-based fluids.

  • Cap Insertion & Pressing
    Guarantees tight, leak-free seals to maintain product integrity during storage and transport.

  • Servo Control & Touch Screen
    User-friendly touchscreen allows for easy adjustments, production recipe storage, and real-time system monitoring.

StationeryProduction

Application in Stationery and Art Supply Packaging

Application Examples
Marker Pens Permanent markers, highlighters
Water-Based Pens Watercolor pens, ink pens
Specialty Ink Pens Brush pens, technical drawing pens

Perfect for manufacturers of school supplies, art materials, and professional writing instruments.

Customer Case Study

An educational stationery supplier in Germany switched from manual filling to the ZS-AFCU1M in 2024. Benefits included:

  • Increased filling speed by 250%

  • Reduced defective seal rate to below 0.3%

  • Decreased labor cost by 60%

  • Enhanced packaging consistency for export markets

Why Choose ZONESUN ZS-AFCU1M?

  • Compact design suitable for small- to mid-volume production

  • Flexible system supports various pen types and inks

  • Easy to clean and maintain

  • Ideal for upgrading from manual to semi/fully automated lines

Contact ZONESUN for Customized Solutions

Looking to streamline your pen manufacturing process?
Contact ZONESUN for tailored machine setup, consultation, or sample test runs.

Boost your efficiency with smarter pen packaging automation.
